Timken 33287 – 33462 (Y5S-33462)
Tapered Roller Bearings - 2TS-DM (Matched Bearing Assembly, Direct Mount)
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
33287 – 33462 (Y5S-33462)
Specifications
Cone Part Number
33287
Cup Part Number
33462
Related Assembly Number(s)
33287-90110
Outer Spacer Part Number
Y5S-33462
Design Unit
Inch
Dimensions
d - Bore
73.025 mm
D - Cup Outer Diameter
117.475 mm
T - Width
60.325 mm
B - Width
60.324 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
0.3 mm
r - Cup Backface "To Clear" Radius2
3.30 mm
db - Cone Backface Backing Diameter
88 mm
Da - Cup Frontface Backing Diameter
113.00 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)3
35900 N
C1 - Dynamic Radial Rating (1 million revolutions)4
241000 N
C5
26800 N
C906
62400 N
Factors
K - Factor7
1.34
e - ISO Factor8
0.44
Y1 - ISO Factor9
1.55
Y2 - ISO Factor10
2.31
