Timken 9118K
Fafnir® Deep Groove Ball Bearings
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
Design Units
Metric
d - Bore
90 mm
Ball Type
STEEL
Manufacturing Part Number
9118KC3
Dimensions
D - Outer Diameter
140 mm
Bearing Width
24 mm
Basic Load Ratings
Ce - Dynamic Radial Rating1
64500 N
C0 - Static Radial Rating
49600 N
Factors
Limiting Speed (Grease)
2609 rpm
Limiting Speed (Oil)
3043 rpm
Abutment and Fillet Dimensions
R - Inner Ring "To Clear" Radius2
1.5 mm
r - Outer Ring "To Clear" Radius3
1.5 mm
da - Inner Ring Backing Diameter
97.54 mm
Da - Outer Ring Backing Diameter
131.06 mm
