Timken HH234048 – HH234010 (HH234010EC)
Tapered Roller Bearings - 2TS-DM (Matched Bearing Assembly, Direct Mount)
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
HH234048 – HH234010 (HH234010EC)
Specifications
Cone Part Number
HH234048
Cup Part Number
HH234010
Related Assembly Number(s)
HH234048-90011
Outer Spacer Part Number
HH234010EC
Design Unit
Inch
Dimensions
d - Bore
152.400 mm
D - Cup Outer Diameter
307.975 mm
T - Width
177.8 mm
B - Width
187.325 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
3.300 mm
r - Cup Backface "To Clear" Radius2
6.86 mm
db - Cone Backface Backing Diameter
191 mm
Da - Cup Frontface Backing Diameter
286.00 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)3
299000 N
C1 - Dynamic Radial Rating (1 million revolutions)4
2010000 N
C5
167000 N
C906
520000 N
Factors
K - Factor7
1.79
e - ISO Factor8
0.33
Y1 - ISO Factor9
2.07
Y2 - ISO Factor10
3.08
