Timken S8KDD
Fafnir® Miniature Ball Bearings
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
Design Units
Imperial
Ball Type
STEEL
Manufacturing Part Number
S8KDD Z1 FS50000;
Dimensions
D - Outer Diameter
41.28 mm
Bearing Width
7.94 mm
Basic Load Ratings
C0 - Static Radial Rating
5440 N
Ce - Dynamic Radial Rating
11300 N
Factors
Limiting Speed (Grease)
9677 rpm
Limiting Speed (Oil)
11290 rpm
Abutment and Fillet Dimensions
R - Inner Ring "To Clear" Radius
0.8 mm
r - Outer Ring "To Clear" Radius1
0.800 mm
da - Inner Ring Backing Diameter
23.60 mm
Da - Outer Ring Backing Diameter
37.10 mm
