NTN NJ406G1
ISO Series Single Row Cylindrical Roller Bearings
(BRAND)：NTN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Technical Specifications
Type
Cylindrical Roller Bearing
Bore Type
Round
Material
Hardened Alloy Steel
Cage Material
High Strength Machined Brass Rivetless w/ square holes
Limiting Speed - Oil
8500 RPM
Configuration
One
Tolerance
ISO Class 0 (RBEC 1)
Oil Hole
w/o Oil Hole
Radial Internal Clearance
CN
Static Load Rating
55000 N
Dynamic Load Rating
62500 N
Enclosure
Open
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
30.000 mm
D
90.000 mm
B
23.000 mm
Fw
45.000 mm
J
50.500 mm
r
1.500 mm
da min
38.000 mm
db min
38.000 mm
Da max
82.000 mm
Db max
82.000 mm
Db min
74.000 mm
r1as max
1.500 mm
