SKF 25096
Metal face seal
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
d1
63.5 mm
Shaft diameter
D
95.56 mm
Housing bore diameter
B1
23.04 mm
Operating width
B
10.72 mm
Housing bore depth
d3
65.53 mm
Seal inside diameter
b
21.34 mm
Width of metal sealing rings
r
1.07 mm
Radius
mass
0.253 kg
Product net weight
