IKO WS110160
Inner Ring for Thrust Roller Bearing, Metric
WS110160 IKO Thrust Bearing Inner Ring
The WS110160 is an IKO inner ring designed for a metric thrust roller bearing arrangement. It is listed within IKO thrust bearings and is identified by order number WS110160.
What is the WS110160?
The WS110160 is an inner ring for a thrust roller bearing. It belongs to the IKO thrust bearings product series and has a carbon steel bearing material designation.
WS110160 Dimensions and Product Data
The supplied specifications identify the inner ring by its metric shaft, bore, outer diameter, width, corner radius, and mass. These details support dimensional comparison with matching assembly components.
- Order Number: WS110160
- Shaft Diameter: 110 mm
- Inside Diameter: 110 mm
- Outer Diameter: 160 mm
- Width: 11.50 mm
- rs min.: 1.1 mm
- Mass: 950.0 g
What dimensions are specified for the WS110160?
The WS110160 has a 110 mm shaft and inside diameter, a 160 mm outer diameter, an 11.50 mm width, and a minimum radius of 1.1 mm. Its listed mass is 950.0 g.
WS110160 Material and Series Information
The product data identifies the WS110160 as a carbon steel thrust bearing component in the IKO thrust bearings category. No additional performance ratings or application claims are provided in the supplied data.
What material and bearing type are listed?
The listed bearing type is Thrust Bearings, and the listed bearing material is Carbon Steel. The component is an IKO WS110160 inner ring for a thrust roller bearing.
