IKO WS3552
Inner Ring for Thrust Roller Bearing, Metric
WS3552 IKO Thrust Bearing Inner Ring
The WS3552 is an IKO inner ring intended for use in a thrust roller bearing arrangement. It is listed in the IKO Thrust Bearings series and has a metric design with carbon steel as the stated bearing material.
What is the WS3552?
The WS3552 is an inner ring for a thrust roller bearing, ordered under order number WS3552 and supplied by IKO.
Metric Dimensions and Product Specifications
- Shaft diameter: 35 mm
- Inside diameter: 35 mm
- Outer diameter: 52 mm
- Width: 3.50 mm
- rs min.: 0.6 mm
- Mass: 31.5 g
- Material: Carbon steel
What are the stated dimensions?
The supplied data lists a 35 mm inside diameter, 52 mm outer diameter, 3.50 mm width, and a minimum fillet radius of 0.6 mm.
Series and Material Information
The WS3552 belongs to the IKO thrust bearing product series and is categorized under Brand > IKO > Thrust Bearings. The listed bearing material is carbon steel, and the component is described as an inner ring for a thrust roller bearing.
What material and category information is provided?
The product data identifies the bearing type as Thrust Bearings and the bearing material as Carbon Steel, with the component categorized under IKO Thrust Bearings.
