INA LR25X30X26,5
Needle Roller Bearings
Inner ring LR, cylindrical
(BRAND)：INA
(Availability)：In Stock
Main Dimensions & Performance Data
d
25 mm
Bore diameter
F
30 mm
Raceway diameter inner ring
B
26.5 mm
Width
rmin
0.3 mm
Minimum chamfer dimension
30 °
Chamfer angle
≈m
0.044 kg
Weight
