NSK 7217BEAT7
Single-Row Angular Contact Ball Bearings
(BRAND)：NSK
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Designations
7217BEAT7
Boundary Dimensions
d
85
mm
Bore diameter
D
150
mm
Outside diameter
B
28
mm
Width
r (min.)
2
mm
Chamfer dimension
r1 (min.)
1
mm
Chamfer dimension
Basic Load Ratings
Cr
106000
N
Basic dynamic load rating
C0r
81500
N
Basic static load rating
Speeds
Grease
3800
min-1
Grease lubrication
Oil (Oil-bath)
5600
min-1
Oil-bath lubrication
a
63.3
mm
Effective load center
Dimensions
da (min.)
95
mm
Diameter of shaft abutment
Da (max.)
140
mm
Diameter of housing abutment
ra (max.)
2
mm
Radius of shaft or housing fillet
