NSK 7218BEAMR
Single-Row Angular Contact Ball Bearings
(BRAND)：NSK
(Availability)：In Stock
Designations
7218BEAMR
Boundary Dimensions
d
90
mm
Bore diameter
D
160
mm
Outside diameter
B
30
mm
Width
r (min.)
2
mm
Chamfer dimension
r1 (min.)
1
mm
Chamfer dimension
Basic Load Ratings
Cr
120000
N
Basic dynamic load rating
C0r
93500
N
Basic static load rating
Speeds
Grease
3600
min-1
Grease lubrication
Oil (Oil-bath)
5300
min-1
Oil-bath lubrication
a
67.4
mm
Effective load center
Dimensions
da (min.)
100
mm
Diameter of shaft abutment
Da (max.)
150
mm
Diameter of housing abutment
ra (max.)
2
mm
Radius of shaft or housing fillet
