NSK 7308BEAMR
Single-Row Angular Contact Ball Bearings
(BRAND)：NSK
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Designations
7308BEAMR
Boundary Dimensions
d
40
mm
Bore diameter
D
90
mm
Outside diameter
B
23
mm
Width
r (min.)
1.5
mm
Chamfer dimension
r1 (min.)
1
mm
Chamfer dimension
Basic Load Ratings
Cr
55500
N
Basic dynamic load rating
C0r
33000
N
Basic static load rating
Speeds
Grease
7100
min-1
Grease lubrication
Oil (Oil-bath)
10000
min-1
Oil-bath lubrication
a
38.8
mm
Effective load center
Dimensions
da (min.)
49
mm
Diameter of shaft abutment
Da (max.)
81
mm
Diameter of housing abutment
ra (max.)
1.5
mm
Radius of shaft or housing fillet
