NSK 7322BEAMR
Single-Row Angular Contact Ball Bearings
(BRAND)：NSK
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Designations
7322BEAMR
Boundary Dimensions
d
110
mm
Bore diameter
D
240
mm
Outside diameter
B
50
mm
Width
r (min.)
3
mm
Chamfer dimension
r1 (min.)
1.1
mm
Chamfer dimension
Basic Load Ratings
Cr
249000
N
Basic dynamic load rating
C0r
226000
N
Basic static load rating
Speeds
Grease
2600
min-1
Grease lubrication
Oil (Oil-bath)
3800
min-1
Oil-bath lubrication
a
98.4
mm
Effective load center
Dimensions
da (min.)
124
mm
Diameter of shaft abutment
Da (max.)
226
mm
Diameter of housing abutment
ra (max.)
2.5
mm
Radius of shaft or housing fillet
