NSK UKX05D1
Ball Bearings
(BRAND)：NSK
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Designations
UKX05D1
Included products
Bearing
Associated products
Adapter sleeve
Nominal Dimensions
d
25
mm
Bore diameter
D
62
mm
Outside diameter
B1
35
mm
Overall bearing width
d1
20
mm
Sleeve bore diameter
d2
38
mm
Outside diameter lock nut
B,B4
26
mm
Width of inner ring
B2
8
mm
Width lock nut including lock washer
C
19
mm
Outer ring width
Ca
4.9
mm
Distance from oil hole centre to raceway centre
d4
40.8
mm
Outside diameter of inner ring
Basic Load Ratings
Cr
19.5
kN
Basic dynamic load rating
C0r
11.3
kN
Basic static load rating
Mass
Mass approx.
0.38
kg
Mass approx.
