NTN 32312C
Tapered Roller Set - Metric Series
(BRAND)：NTN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Technical Specifications
Type
Tapered Roller Bearing
Bore Type
Round
Material
Through Hardened Steel
Style
Cone & Cup
Precision Rating
Class 4
Configuration
One
Lubrication
w/o Oil Hole
e (Axial Load Factor)
0.55
Y2 (Axial Load Factor)
1.10
Enclosure
Open
Weight
2.985 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
60.000 mm
D
130.000 mm
C
37.051 mm
B
46.050 mm
T
48.600 mm
r
2.500 mm
R
3.0 mm
