Timken 241/750KYMDW73W879C
Spherical Roller Bearings - Brass Cage
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Specifications
Design Unit
Metric
d - Bore
750 mm
Bore_Taper
1/30
Cage Type
YMD
Cage Material
Brass
Dimensions
D - Outer Diameter
1220 mm
B' - Inner Ring Width
475 mm
B - Outer Ring Width
475 mm
Abutment and Fillet Dimensions
R - Inner Ring "To Clear" Radius1
7 mm
r - Outer Ring "To Clear" Radius2
7 mm
da - Inner Ring Backing Diameter
839.000 mm
Da - Outer Ring Backing Diameter
1114.000 mm
Basic Load Ratings
C0 - Static Radial Rating
38700000 N
C1(2) - Dynamic Radial Rating (Two-Rows)
19800000 N
Factors
e - ISO Factor3
0.36
Y0 - ISO Factor4
1.82
Y1 - ISO Factor5
1.86
Y2 - ISO Factor6
2.77
Reference Thermal Speed Rating (Grease)
100 rpm
Reference Thermal Speed Rating (Oil)7
110 rpm
Cg - Geometry Factor8
0.1309
