Timken 39K
Fafnir® Deep Groove Ball Bearings
(BRAND)：TIMKEN
(Availability)：In Stock
Specifications
Design Units
Metric
d - Bore
9 mm
Ball Type
STEEL
Manufacturing Part Number
39K Z1 FS50000
Dimensions
D - Outer Diameter
26 mm
Bearing Width
8 mm
Basic Load Ratings
Ce - Dynamic Radial Rating1
5080 N
C0 - Static Radial Rating
1970 N
Factors
Limiting Speed (Grease)
16668 rpm
Limiting Speed (Oil)
19446 rpm
Abutment and Fillet Dimensions
R - Inner Ring "To Clear" Radius2
0.04 mm
r - Outer Ring "To Clear" Radius3
0.04 mm
da - Inner Ring Backing Diameter
12.45 mm
Da - Outer Ring Backing Diameter
23.11 mm
