FAG 21318-E1-XL
Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
(BRAND)：FAG
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
90 mm
Bore diameter
D
190 mm
Outside diameter
B
43 mm
Width
Cr
380,000 N
Basic dynamic load rating, radial
C0r
415,000 N
Basic static load rating, radial
Cur
48,500 N
Fatigue load limit, radial
CG
4,850 1/min
Limiting speed
nϑr
3,600 1/min
Reference speed
≈m
6.124 kg
Weight
Mounting dimensions
da min
104 mm
Minimum diameter shaft shoulder
Da max
176 mm
Maximum diameter of housing shoulder
ra max
2.5 mm
Maximum recess radius
