FAG 718/710-MPB-P5
Angular Contact Ball Bearings
Angular contact ball bearing 718..-MPB, single row, solid brass cage
(BRAND)：FAG
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
710 mm
Bore diameter
D
870 mm
Outside diameter
B
74 mm
Width
Cr
590,000 N
Basic dynamic load rating, radial
C0r
1,460,000 N
Basic static load rating, radial
Cur
30,000 N
Fatigue load limit, radial
nG
1,000 1/min
Limiting speed
nϑr
520 1/min
Reference speed
≈m
95 kg
Weight
Mounting dimensions
da min
724.6 mm
Minimum diameter of shaft shoulder
Da max
855.4 mm
Maximum diameter of housing shoulder
Db max
863 mm
Maximum diameter of housing shoulder
ra max
3 mm
Maximum fillet radius of shaft
ra1 max
1.5 mm
Maximum fillet radius of housing
