FAG UK205-OSE
Insert Ball Bearings and Belt Tension Pulleys
(BRAND)：FAG
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
25 mm
Bore diameter
DSP
52 mm
Outside diameter
B
23 mm
Width
Cur
410 N
Fatigue load limit, radial
Cr
14,900 N
Basic dynamic load rating, radial
C0r
7,800 N
Basic static load rating, radial
≈m
0.146 kg
Weight
