IKO NAG4926
Roller Bearings, Full Complement, High Carbon Steel, Oil Hole
NAG4926 IKO Roller Bearing Overview
The NAG4926 is an IKO roller bearing in the Roller Bearings series. It is specified as a full complement bearing made from high carbon chrome steel, and the product data identifies an oil hole feature.
What bearing type and structure are listed for NAG4926?
The listed bearing type is Roller Bearings, and the internal structure is specified as Full Complement. The product is presented under the category path Brand > IKO > Roller Bearings.
NAG4926 Dimensions and Product Specifications
The supplied dimensional data for the NAG4926 includes the following values:
- Shaft diameter: 130 mm
- Inside diameter: 130 mm
- Outer diameter: 180 mm
- Width: 50 mm
- rs min.: 2.0 mm
- Diameter values: 147.0 mm and 165.5 mm
What additional specification is recorded for this bearing?
The product data records a mass of 3750.000 g. It also identifies the bearing material as High Carbon Chrome Steel and describes the bearing as having an oil hole.
NAG4926 Load Rating Information
The supplied product data includes basic load-rating figures for the IKO NAG4926:
- Basic dynamic load rating: 240000 N
- Basic static load rating: 495000 N
Are application or installation details included in the supplied data?
No. The supplied information identifies the model, brand, series, dimensions, material, structure, oil hole feature, mass, and basic load ratings. Application or installation requirements should be confirmed using the relevant engineering or manufacturer documentation when required.
