IKO NAS5009ZZNR
Roller Bearings for Sheaves, High Carbon Steel, Oil Hole, Shielded
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5009ZZNR
Shaft Diameter
45
mm
Inside diameter
45
mm
Outer Diameter
75
mm
Diameter
78.8
mm
Width of innerring
40
mm
Width
39
mm
Dimension
30
mm
Dimension
4.5
mm
Dimension
2.0
mm
Chamfer
1.5
mm
rs min.
0.6
mm
Diameter
56.0
mm
Basic dynamic load rating
95500
N
Basic static load rating
144000
N
Mass
0.70
kg
