IKO NAS5010UUNR
Roller Bearings for Sheaves, High Carbon Steel, Oil Hole, With Seals
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5010UUNR
Shaft Diameter
50
mm
Inside Diameter
50
mm
Outer Diameter
80
mm
Diameter
83.8
mm
Width of innerring
40
mm
Width
39
mm
Dimension
30
mm
Dimension
4.5
mm
Dimension
2.0
mm
Chamfer
1.5
mm
rs min.
0.6
mm
Diameter
61.0
mm
Basic dynamic load rating
100000
N
Basic static load rating
158000
N
Mass
0.75
kg
