IKO NAS5013UUNR
Roller Bearings for Sheaves, High Carbon Steel, Oil Hole, With Seals
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5013UUNR
Shaft Diameter
65
mm
Inside Diameter
65
mm
Outer Diameter
100
mm
Diameter
104.8
mm
Width of innerring
46
mm
Width
45
mm
Dimension
34
mm
Dimension
5.5
mm
Dimension
2.5
mm
Chamfer
2.0
mm
rs min.
0.6
mm
Diameter
78.0
mm
Basic dynamic load rating
128000
N
Basic static load rating
224000
N
Mass
1.30
kg
