IKO NAS5015ZZNR
Roller Bearings for Sheaves, High Carbon Steel, Oil Hole, Shielded
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5015ZZNR
Shaft Diameter
75
mm
Inside diameter
75
mm
Outer Diameter
115
mm
Diameter
119.5
mm
Width of innerring
54
mm
Width
53
mm
Dimension
42
mm
Dimension
5.5
mm
Dimension
2.5
mm
Chamfer
2.0
mm
rs min.
0.6
mm
Diameter
91.0
mm
Basic dynamic load rating
179000
N
Basic static load rating
308000
N
Mass
2.00
kg
