IKO NAS5016ZZNR
Roller Bearings for Sheaves, High Carbon Steel, Oil Hole, Shielded
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5016ZZNR
Shaft Diameter
80
mm
Inside diameter
80
mm
Outer Diameter
125
mm
Diameter
129.5
mm
Width of innerring
60
mm
Width
59
mm
Dimension
48
mm
Dimension
5.5
mm
Dimension
2.5
mm
Chamfer
2.0
mm
rs min.
0.6
mm
Diameter
97.0
mm
Basic dynamic load rating
251000
N
Basic static load rating
428000
N
Mass
2.65
kg
