IKO NAS5017ZZNR
Roller Bearings for Sheaves, High Carbon Steel, Inner Ring With Oil Holes, With Shields
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5017ZZNR
Shaft Diameter
85
mm
Inside diameter
85
mm
Outer Diameter
130
mm
Diameter
134.5
mm
Width of innerring
60
mm
Width
59
mm
Dimension
48
mm
Dimension
5.5
mm
Dimension
2.5
mm
Chamfer
2.0
mm
rs min.
0.6
mm
Diameter
101.0
mm
Basic dynamic load rating
257000
N
Basic static load rating
446000
N
Mass
2.80
kg
