IKO NAS5019ZZNR
Roller Bearings for Sheaves, High Carbon Steel, Inner Ring With Oil Holes, With Shields
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5019ZZNR
Shaft Diameter
95
mm
Inside diameter
95
mm
Outer Diameter
145
mm
Diameter
150.4
mm
Width of innerring
67
mm
Width
66
mm
Dimension
54
mm
Dimension
6.0
mm
Dimension
2.5
mm
Chamfer
2.5
mm
rs min.
0.6
mm
Diameter
114.0
mm
Basic dynamic load rating
312000
N
Basic static load rating
562000
N
Mass
3.90
kg
