IKO NAS5020UUNR
Roller Bearings for Sheaves, High Carbon Steel, Inner Ring With Oil Holes, With Seals
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5020UUNR
Shaft Diameter
100
mm
Inside Diameter
100
mm
Outer Diameter
150
mm
Diameter
155.4
mm
Width of innerring
67
mm
Width
66
mm
Dimension
54
mm
Dimension
6.0
mm
Dimension
2.5
mm
Chamfer
2.5
mm
rs min.
0.6
mm
Diameter
118.0
mm
Basic dynamic load rating
318000
N
Basic static load rating
584000
N
Mass
4.05
kg
