IKO NAS5022UUNR
Roller Bearings for Sheaves, High Carbon Steel, Inner Ring With Oil Holes, With Seals
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5022UUNR
Shaft Diameter
110
mm
Inside Diameter
110
mm
Outer Diameter
170
mm
Diameter
175.4
mm
Width of innerring
80
mm
Width
79
mm
Dimension
65
mm
Dimension
7.0
mm
Dimension
2.5
mm
Chamfer
3.0
mm
rs min.
1.0
mm
Diameter
130.0
mm
Basic dynamic load rating
384000
N
Basic static load rating
697000
N
Mass
6.50
kg
