IKO NAS5034UUNR
Roller Bearings for Sheaves, High Carbon Steel, Inner Ring With Oil Holes, With Seals
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5034UUNR
Shaft Diameter
170
mm
Inside Diameter
170
mm
Outer Diameter
260
mm
Diameter
270.0
mm
Width of innerring
122
mm
Width
121
mm
Dimension
99
mm
Dimension
11.0
mm
Dimension
4.0
mm
Chamfer
3.5
mm
rs min.
1.5
mm
Diameter
204.5
mm
Basic dynamic load rating
857000
N
Basic static load rating
1730000
N
Mass
22.50
kg
