IKO NAS5040ZZNR
Roller Bearings, Full Complement, High Carbon Steel, Oil Hole
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAS5040ZZNR
Shaft Diameter
200
mm
Inside diameter
200
mm
Outer Diameter
310
mm
Diameter
326.0
mm
Width of innerring
150
mm
Width
149
mm
Dimension
120
mm
Dimension
14.5
mm
Dimension
5.0
mm
Chamfer
3.5
mm
rs min.
1.5
mm
Diameter
242.0
mm
Basic dynamic load rating
1310000
N
Basic static load rating
2650000
N
Mass
40.50
kg
