IKO NATB5903
Combined with Three Point Contact Ball Bearing
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
NATB5903
Shaft Diameter
17
mm
Inside Diameter
17
mm
Outside Diameter
30
mm
Width
18
mm
Width of innerring
20
mm
rs min.
0.3
mm
Inscribed circle diameter
22
mm
da min
19
mm
Da max
28
mm
Basic dynamic load rating (Radial)
8220
N
Basic dynamic load rating (Axial)
2050
N
Basic static load rating (Radial)
11500
N
Basic static load rating (Axial)
3340
N
Mass
58.5
g
