IKO NAU4918UU
Caged Roller Bearings, High Carbon Steel, Outer Ring With Oil Holes, With Seals
(BRAND)：IKO
(Availability)：In Stock
Order Number
NAU4918UU
Shaft Diameter
90
mm
Inside Diameter
90
mm
Outer Diameter
125
mm
Width
35
mm
rs min.
1.5
mm
Diameter
101.0
mm
Diameter
115.5
mm
Basic dynamic load rating
79500
N
Basic static load rating
130000
N
Mass
1210.0
g
The IKO NAU4918UU Is a Caged Roller Bearing
What type of bearing is the NAU4918UU?
The IKO NAU4918UU belongs to the Roller Bearings product series and uses a cage-type internal structure. The supplied data identifies it as a caged roller bearing with seals and an outer ring designed with oil holes.
- Brand: IKO
- Model: NAU4918UU
- Bearing type: Roller Bearings
- Internal structure: Cage Type
The NAU4918UU Has Documented Dimensions and Material Data
What dimensions and material are listed for this bearing?
The bearing is specified with a 90 mm shaft and inside diameter, a 125 mm outer diameter, and a 35 mm width. The listed bearing material is high carbon chrome steel, while the descriptive product information also refers to high carbon steel.
- Shaft diameter: 90 mm
- Inside diameter: 90 mm
- Outer diameter: 125 mm
- Width: 35 mm
- rs min.: 1.5 mm
- Additional diameters: 101.0 mm and 115.5 mm
- Mass: 1210.0 g
The NAU4918UU Includes Load Ratings and Sealing Features
What load ratings and configuration details are provided?
The supplied data lists a basic dynamic load rating of 79500 N and a basic static load rating of 130000 N. The product description also states that the bearing includes seals and an outer ring with oil holes.
- Basic dynamic load rating: 79500 N
- Basic static load rating: 130000 N
- Outer ring feature: Oil holes
- Sealing: With seals
