IKO PB12
Spherical Bushing Pilloball, Insert Type/ Lubrication Type , High Carbon Steel
(BRAND)：IKO
(Availability)：In Stock
Order Number
PB12
Inside Diameter
12
mm
Outer Diameter
30
mm
Width
12.00
mm
Width of innerring
16
mm
Diameter
15.4
mm
rs min.
0.2
mm
Diameter of Ball
22.23
mm
Dynamic load capacity
13100
N
Static load capacity
31400
N
Mass
58.0
g
