IKO PB5
Spherical Bushing Pilloball, Insert Type/ Lubrication Type , High Carbon Steel
(BRAND)：IKO
(Availability)：In Stock
Order Number
PB5
Inside Diameter
5
mm
Outer Diameter
16
mm
Width
6.00
mm
Width of innerring
8
mm
Diameter
7.7
mm
rs min.
0.2
mm
Diameter of Ball
11.11
mm
Dynamic load capacity
3270
N
Static load capacity
7850
N
Mass
8.5
g
