IKO PB6
Spherical Bushing Pilloball, Insert Type/ Lubrication Type , High Carbon Steel
(BRAND)：IKO
(Availability)：In Stock
Order Number
PB6
Inside Diameter
6
mm
Outer Diameter
18
mm
Width
6.75
mm
Width of innerring
9
mm
Diameter
9.0
mm
rs min.
0.2
mm
Diameter of Ball
12.70
mm
Dynamic load capacity
4200
N
Static load capacity
10100
N
Mass
13.0
g
