IKO PB8
Spherical Bushing Pilloball, Insert Type/ Lubrication Type , High Carbon Steel
(BRAND)：IKO
(Availability)：In Stock
Order Number
PB8
Inside Diameter
8
mm
Outer Diameter
22
mm
Width
9.00
mm
Width of innerring
12
mm
Diameter
10.4
mm
rs min.
0.2
mm
Diameter of Ball
15.88
mm
Dynamic load capacity
7010
N
Static load capacity
16800
N
Mass
24.0
g
