IKO PHS14EC
Rod End, Metric, Female Thread, Maintenance Free Type (Right Handed)
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
PHS14EC
Inside Diameter
14
mm
Thread
M14x2
Diameter
34
mm
Width
13.50
mm
Width of innerring
19
mm
Diameter
16.9
mm
Total Lenght
74
mm
Dimension
57
mm
Length
27.0
mm
Dimension
8.0
mm
Width
22.0
mm
Diameter
20.0
mm
Diameter
25.0
mm
r1s min
0.2
mm
Diameter of Ball
25.400
mm
Dynamic load capacity
33600
N
Static load capacity
17200
N
Mass
160.0
g
