IKO PHS30
Rod End, Metric, Insert Type, Female Thread (Right Handed)
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
PHS30
Inside Diameter
30
mm
Thread
M30x2
Diameter
70
mm
Width
25.0
mm
Width of innerring
37
mm
Diameter
34.8
mm
Total Lenght
145
mm
Dimension
110
mm
Length
56
mm
Dimension
15.0
mm
Width
41.0
mm
Diameter
40.0
mm
Diameter
50.0
mm
r1s min
0.6
mm
Diameter of Ball
50.800
mm
Dynamic load capacity
62300
N
Static load capacity
92200
N
Mass
1130.0
g
