IKO PHS6A
Rod End, Metric, Insert Type, Female Thread (Right Handed)
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
PHS6A
Inside Diameter
6
mm
Thread
M6x1
Diameter
18
mm
Width
6.8
mm
Width of innerring
9
mm
Diameter
9.0
mm
Total Lenght
39
mm
Dimension
30
mm
Length
14
mm
Dimension
5.0
mm
Width
11.0
mm
Diameter
10.0
mm
Diameter
13.0
mm
r1s min
0.2
mm
Diameter of Ball
12.700
mm
Dynamic load capacity
4200
N
Static load capacity
6910
N
Mass
25.0
g
