IKO PHS8A
Rod End, Metric, Insert Type, Female Thread (Right Handed)
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
PHS8A
Inside Diameter
8
mm
Thread
M8x1.25
Diameter
22
mm
Width
9.0
mm
Width of innerring
12
mm
Diameter
10.4
mm
Total Lenght
47
mm
Dimension
36
mm
Length
17
mm
Dimension
5.0
mm
Width
14.0
mm
Diameter
12.5
mm
Diameter
16.0
mm
r1s min
0.2
mm
Diameter of Ball
15.875
mm
Dynamic load capacity
7010
N
Static load capacity
10200
N
Mass
43.0
g
