IKO TRU304830
Roller Bearings, Cage Type, High Carbon Steel, Oil Hole
(BRAND)：IKO
(Availability)：In Stock
Order Number
TRU304830
Shaft Diameter
30
mm
Inside Diameter
30
mm
Outer Diameter
48
mm
Width
30
mm
rs min.
0.3
mm
Diameter
35.0
mm
Diameter
42.5
mm
Basic dynamic load rating
29400
N
Basic static load rating
46600
N
Mass
197.0
g
TRU304830 IKO Roller Bearing Overview
What is the TRU304830?
The TRU304830 is an IKO roller bearing in the Roller Bearings product series. It uses a cage-type internal structure and is listed with an oil hole and high carbon steel bearing construction.
- Brand: IKO
- Model: TRU304830
- Bearing Type: Roller Bearings
- Internal Structure: Cage Type
- Bearing Material: High Carbon Chrome Steel
TRU304830 Dimensions and Specifications
What dimensions and load values are provided?
The supplied product data lists the following specifications for the TRU304830 roller bearing:
- Shaft Diameter: 30 mm
- Inside Diameter: 30 mm
- Outer Diameter: 48 mm
- Width: 30 mm
- rs min.: 0.3 mm
- Additional Diameters: 35.0 mm and 42.5 mm
- Basic Dynamic Load Rating: 29400 N
- Basic Static Load Rating: 46600 N
- Mass: 197.0 g
TRU304830 Product Identification
How is this bearing identified in the product range?
The TRU304830 is categorized under Brand > IKO > Roller Bearings. The product description identifies it as a cage-type roller bearing made with high carbon steel and featuring an oil hole.
- Confirm the order number: TRU304830
- Verify the bore, outside diameter, and width: 30 mm x 48 mm x 30 mm
- Review the listed material, structure, and load-rating data before selection.
