INA G1015-KRR-B-AS2/V
Insert Ball Bearings and Belt Tension Pulleys
Radial insert ball bearing G1..-KRR-B-AS2/V
(BRAND)：INA
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
23.8125 mm
Bore diameter
d
0.9375 in
Bore diameter, inch
DSP
52 mm
Outside diameter
B
34.9 mm
Width
Cur
400 N
Fatigue load limit, radial
B1
44.5 mm
Locking collar total width
Cr
14,000 N
Basic dynamic load rating, radial
C0r
7,800 N
Basic static load rating, radial
≈m
254 g
Weight
