INA OC105-DC-B-VA-FD
Insert Ball Bearings and Belt Tension Pulleys
(BRAND)：INA
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
33.338 mm
Bore diameter
d
1.3125 in
Bore diameter, inch
DSP
72 mm
Outside diameter
Cur
1,000 N
Fatigue load limit, radial
B1
44.5 mm
Locking collar total width
Cr
21,900 N
Basic dynamic load rating, radial
C0r
12,500 N
Basic static load rating, radial
≈m
0.51 kg
Weight
