INA SL185012-A
Cylindrical Roller Bearings
Cylindrical roller bearing SL1850..-A, full complement roller set, two-row, semi-locating bearing, 1 rib on outer ring, 3 ribs on inner ring, type SL18
(BRAND)：INA
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
60 mm
Bore diameter
D
95 mm
Outside diameter
B
46 mm
Width
Cr
187,000 N
Basic dynamic load rating, radial
C0r
285,000 N
Basic static load rating, radial
Cur
39,000 N
Fatigue load limit, radial
CG
4,350 1/min
Limiting speed
nϑr
2,800 1/min
Reference speed
≈m
1.19 kg
Weight
Mounting dimensions
d min
71.5 mm
Minimum shaft shoulder
da min
71.7 mm
Minimum diameter shaft shoulder
Da max
81.9 mm
Maximum diameter of housing shoulder
ra max
1.1 mm
Maximum recess radius
ra1 max
2 mm
Maximum recess radius
De min
81.9 mm
Minimum diameter of housing shoulder
