MCGILL SB-22311
BEARING
(BRAND)：MCGILL
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Description
BORE A MM
55
BORE A INCH
2.1654
OUTSIDE DIAMETER B MM
120
OUTSIDE DIAMETER INCH
4.7244
WIDTH C MM
43
WIDTH C INCH
1.6929
SHOULDER DIMENSIONS r (1)
.079
SHOULDER DIMENSIONS D
2 9/16
SHOULDER DIMENSIONS E
4 1/4
SHOULDER DIMENSIONS H (2)
21/64
SHOULDER DIMENSIONS J MIN.
1/8
LIM. SPEED (3) RPM
3800
ABMA BASIC DYNAMIC RATING POUNDS
41300
ADAPTER NUMBER (4)
SNW 111
ADAPTER DIMENSIONS SHAFT DIAM.
1 15/16
ADAPTER DIMENSIONS B1
2 33/64
ADAPTER DIMENSIONS S
9/16
ADAPTER DIMENSIONS D1
2 31/32
BRG. WT. LBS.
5.3
