NSK UKC307D1
Cartridge Units
(BRAND)：NSK
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Designations
UKC307D1
Included products
Bearing
Housing
C307D1
Housing
Associated products
Adapter sleeve
Nominal Dimensions
d
30
mm
Bore diameter
A
32
mm
Base width
r
3
mm
Housing Chamfer dimension
H
110
mm
Outer diameter
B,B1
43
mm
Width of inner ring
B1
43
mm
Width of inner ring
Basic Load Ratings
Cr
33.5
kN
Basic dynamic load rating
C0r
19.1
kN
Basic static load rating
Mass
mass
1.8
kg
Mass approx.
