NTN UCS213N
Set Screw Type Bearings - Cylindrical O.D.
(BRAND)：NTN
(Availability)：In Stock
Technical Specifications
Type
Insert Bearing
Bore Type
Round
Bearing Type
Ball Bearing
Material
Through Hardened Steel
Ball Material
Through Hardened
Limiting Speed - Grease
2400 RPM
Seal Type
Contact
Seal Material
Nitrile Rubber
Precision Rating
ISO Class 0
Performance
Standard Duty
Locking Device
2 -120° Set Screw
Lubrication
No
Radial Internal Clearance
CN
Static Load Rating
40000 N
Dynamic Load Rating
57500 N
Enclosure
Double Sealed
Weight
9.340 kg
Operating Temperature Range
-40 to 120 ºC
Dimensional Specifications
d
65.000 mm
D
120.000 mm
C
32.000 mm
B
65.100 mm
r
2.000 mm
r1
2.000 mm
ds
M10x1.25
G
10 mm
d4
82.5 mm
S1
39.7 mm
S
25.4 mm
F
6.8 mm
Specifications
Radial Dynamic Load Rating
57500 N
Lubrication
No
Radial Static Load Rating
40000 N
