SKF 13944
Large-size self-aligning ball bearing
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
d
220.0 mm
Bore diameter
D
300.0 mm
Outside diameter
B
60.0 mm
Width
d1
248.9 mm
Shoulder diameter inner ring
D1
277.8 mm
Shoulder diameter outer ring
b
8.3 mm
Width annular lubrication groove at outer ring
K
4.5 mm
Diameter lubrication hole (outer ring)
r1,2
2.1 mm
Chamfer dimension
mass
11.0 kg
Product net weight
